FABRICATION EQUIPMENT

TRUMPF T- 260C,
CNC VERTICAL ROTATION TURRET PUNCH PRESS.
PUNCHING FORCE 33 TONS. NO. TOOL STATIONS 22.
FULL ROTATION +/-.100
POSITION ACCURACY: +/- .004" REPEATABILITY: +/- .001"
TRAVEL DISTANCE: 103" X ; 50"Y. POSITION SPEED: 1770 IPM.
MAX. MATERIAL CAPABILITY: 0.375"

(2) Erht Bus Bar Machines
5/8” X 8.0” x 236” CAPACITY
1@ 9 tools
1@ 6 tools


MECHANICAL/ HYDRALIC  PRESSES

PACIFIC HYDRAULIC C- FRAME PRESS
MAJOR USE FOR STAMP DIE PROCESSING
MODEL # 200 PF II
CAPACITY 200 TONS
STROKE 12”
OPEN HEIGHT 23”: CLOSED HEIGHT 11”
THROAT DEPTH 20”

PRESS RITE #70 FLYWHEEL PRESS
PUNCHING FORCE 70 TONS.
TRAVEL DISTANCE: 4" W/11" SHUT HEIGHT

NIAGARA MODEL 45 PUNCH PRESS
(USED FOR STAMP DIE OPERATIONS)
PUNCHING FORCE: 45 TONS.
TRAVEL DISTANCE: 3.5" W/ 10" SHUT HEIGHT

STAMTEC G2-250 MECHANICAL PRESS
BOLSTER AREA 106"x 35"
250 METRIC TONS

NIAGRA M60 - 60 TON PRESS

MINSTER # 60 - 60 TON PRESS

BROWN AND BOGGS 15 LW - 40 TON PRESS

NIAGRA E-60 - 60 TON PRESS


BENDING PRESSES

ACCURPRESS 7606 HYDRAULIC PRESS BRAKE
6 FT. BED LENGTTRAVEL DISTANCE: 23"
MAX. MATERIAL CAPABILITY: 1"
OPERATING FORCE: 60 TONS.

ACCURPRESS 7305 HYDRAULIC PRESS BRAKE
MODEL#: 7305 W/ 5 FT. BED LENGTH
TRAVEL DISTANCE: 23" BACKSTOP
MAX. MATERIAL CAPABILITY: 1"
OPERATING FORCE: 30 TONS.

EUROMAC DIGIBEND 720
HORIZONTAL HYDRAULIC BENDING PRESS
MAJOR USE: BENDING FLAT BARS (RADIUS BENDS)
TRAVEL DISTANCE: 20" BACKSTOP
MAX. MATERIAL CAPACITY: 4.72" X 79"
OPERATING FORCE: 72 TONS

PACIFIC HYDRAULIC PRESS BRAKE
JENESIS II MODEL# J-140-10 w/ 10' BED LENGTH
TRAVEL DISTANCE: 24" X-AXIS BACKGAUGE
OPERATING FORCE: 110 TONS

SHEARING AND SAWING

KASTO MODEL WAMQ AUTOMATIC COLD SAW
¼” to 12” CUT LENGTH
3  1/8” ROUND CAP.
3  1/8” SQUARE CAP.
4  ½” x 3” RECTANGLE SHAPES

WYSONG #1252 HYDRAULIC SHEAR
MECHANICAL TABLE SHEAR
MODEL #: 1252
TRAVEL DISTANCE: 36" BACKSTOP
MAX. MATERIAL CAPABILITY: 1/4" THICK X 120" WIDE

HEM SAW MODEL H105
HIGH SPEED HORIZONTAL PRODUCTION BAND SAW
SAW CAPACITY: 14" ROUND; 16" FLAT
TRAVEL DISTANCE: 0-24" WITH UNLIMITED MULTI-SHUTTLE
STROKE
FEED RATE: 0-3 INCHES/SECOND
POSITION ACCURACY: +/- .001 INCHES

MISC CUSTOM BAR SHEARING DIE
MECHANICAL BAR SHEAR
MATERIAL CAPABILITY:
1/8" X 10" MIN.
1/2" X 5" MAX.
FLAT BAR LENGTHS: 1" TO 120"
POSITION ACCURACY: +/- .005"

SHARP LMV 50 MANUAL MILL
X-AXIS POWER FEED
QUICK CHANGE TOOLING
DIGITAL READOUT

DEBURRING
WALTER TROWAL DD110
& CD200 VIBRATORY FINISHING MACHINES

WELDING/BRAZING
LINCOLN POWER WAVE 455 MIG
LINCOLN POWER MIG 255 W/HIGH FREQUENCY
PROPYLENE BRAZE WELDING
PROGRESSIVE MODEL 302E59-18 RESISTANCE WELDER
